CPPSHUTTLE/PE Plastic Pallet
48x40 Rackable Plastic Pallet

Notice: 10,000 Minimum Order Quantity
The CPPSHUTTLE/PE at a glance:
- Plastic (HDPE/PP)
- New
- 48x40 (Standard)
- 47.2x31.5x5.5 inch
- 1200x800x140 mm
- 33.0 lbs
- 22,000 lb static
- 4,400 lb dynamic
- 2,800 lb racking
- Open Deck
- 3 Runner Base
- Rackable
- Multi-Trip
- Captive
- Air Freight
Get a Price - CPPSHUTTLE/PE
Pallet Features
48x40 Inches
Also known as a GMA pallet the 48x40 dimensions of this pallet make it the most popular size of all industrial pallets in the US.
Standard US
Popularized by the Grocery Manufacturers Association the 48x40 dimensions of this pallet are standard in the US for most any use.
Specialty
The CPPSHUTTLE/PE is a specialty Plastic Pallet Shuttle designed to solve problems in specific applications.
Open Deck
The ventilated top deck of this plastic pallet provides good airflow plus the open design works well when strapping product.
3 Runner Base
3 runner plastic pallets like the CPPSHUTTLE/PE often pair well with edge racking systems.
Rackable
This rackable plastic pallet works in warehouse racking systems by using support from the 3 runner style bottom deck.
New Pallet
Combining low weight with high strength makes new pallets more affordable than ever for better performance at a lower cost per trip.
Plastic Pallets
Plastic pallets like the CPPSHUTTLE/PE are lightweight and durable. Its uniform length and width provide ease of use and safety.
Food Grade
Place packaged foods and drinks on this food grade plastic pallet. The plastic design is easy to clean in the event of a break or spill.
Multi-Trip
Get more turns using the CPPSHUTTLE/PE multi-trip plastic pallet and easily win back startup costs with durable and reliable plastic.
In-House
Use the CPPSHUTTLE/PE captive plastic pallet in closed loops to satisfy in-house reusability requirements with the reliability of plastic.
Air Freight
Save costs when shipping cargo via air with the CPPSHUTTLE/PE air freight plastic pallet. Perfect for single use and one-way air shipment.
Dynamic Load
Supporting 4,400 lbs of dynamic load when moved by a forklift or hand jack, this pallet works well in heavy duty applications.
CPPSHUTTLE/PE Plastic Pallet
Quick Facts
- Condition
- New
- Material
- Plastic (HDPE/PP)
- High-Density Polyethylene/Polypropylene
- Size
- 48x40 (Standard US)
- Dimensions
- 47.2x31.5x5.5 inch
- 1200x800x140 mm
- Weight
- 33.0 lbs
- Static Load
- 22,000 lbs
- Dynamic Load
- 4,400 lbs
- Racking Load
- 2,800 lbs
- Top Deck
- Open
- Bottom Base
- 3 Runner - Unidirectional Long Side
Special Features
Storage and transport solution for automated high-racking systems.
- Designed for use in ASRS systems
- Easy-to-clean hygienic design
- Suitable for packaged food items
(not approved for direct food contact) - Impervious to acids, fats, solvents and odors
- Resists water absorption & bacteria growth
- Inert to infestation, mold and mildew
- Consistently dimensionally accurate
- Exempt from ISPM 15 shipping regulations


CPPSHUTTLE/PE Specifications
Notes & Availability
- Minimum Order Quantity
Weights & Measures
- 48x40 (Standard US)
- 47.2x31.5x5.5 inches
- 1200x800x140 mm
- 33.0 lbs
- 22,000 lb static load
- 4,400 lb dynamic load
- 2,800 lb racking load
TL (truckload) quantities are approximate and may vary by transport equipment or other factors.
Material
- New Pallet
- Plastic (HDPE/PP)
- High-Density Polyethylene/Polypropylene
- Recycled Material Option
- Virgin Material Option
- Color Options: Black, Gray/Custom*
- Recycled*
*Custom colors and markings available in virgin material. (Minumum quantities required.)
Design
- Rackable
- Open Top Deck
- 3 Runner - Unidirectional Long Side
- 2-way Entry
Usage & Environment
- Pallet Shuttle
- Specialty or Industry Pallet
- Multi-Trip
- Captive
- ISPM-15 Exempt
- Air Freight Friendly
- Non-contact Food Grade
- Pharmaceutical
Watch A Video
A shuttle is a a smart transport solution to convey and store pallets in automated high-rack storage systems. The shuttle allows almost any pallet type to be used in conveyor systems. Watch the shuttle in action in the video below:
Specs subject to change without notice. Provided for informational purposes only. Technical data are guideline values and may vary based on intended use, features, raw materials and environment. Nothing shall be construed as warranties or guarantees, express or implied, regarding products or their use, application, performance or otherwise.
